3659x2058x2185 Slide-In Camper Truck Box Perfect for FORD Dodge Chevrolet GMC PickUp

Name: 3659x2058x2185 SlideIn Camper Truck Box Perfect for FORD Dodge Chevrolet GMC PickUp
Brand: GET VEHICLES
Price: 9 USD

Quality 3659x2058x2185 Slide-In Camper Truck Box Perfect for FORD Dodge Chevrolet GMC PickUp wholesale

Max Payload : 3T

Place of Origin : China

Size : 3659x2058x2185

Brand Name : GET VEHICLES

OE NO. : GET.7EXP.088186

color : FRP White or Customize

Material : FRP Thermo Composite Meteials

Suitable Truckj : Pickup with 8ft Cargo Box

Outside dimensions (L x W x H) : 3659 x 2058 x 2185

Total dry weight (kg) : 430

Wall thickness and Insulation value : 50mm, 0.296 K.m2/W

Roof Skylights (HxW) : Roof Skylight 700 x 500 mm (HxW)

Fire-Retardant Grade : "B" , According to EN 13501-01

Windows (HxW) : Double Glazing Acrylic Glass Insulation Caravan Windows

Garage hatch (Hx W) : Aluminum Insulation Hatches

Embedded Frame : Side Awing Fame, Roof Rail ,Rear Spare Tire Frame

Working Experience : 35 years for Composite Materials

Price : $9,550.00/units 1-4 units

Contact Now

Product Overview

8ft Pick-Up Truck Mounted Alcove Slide In Campering Box for DIY Flatbed RV Truck Motorhome

The GET industry Alcove-Box concept provides an excellent basis for family, long-term journey, and expedition vehicles. 1. The alcove accommodates either a fixed double bed across its width or two single beds in the direction of travel. This option offers comfortable twin beds and leaves space in the rear for a cozy round sofa. The alcove height can be tailored individually. 2. For families the Alcove-Box can offer bunk and lift beds, generously proportioned seating areas, family sized bathrooms and kitchens as well as large garages with a lowered/retractable floor in your choice. 3. The Alcove-Box is available up to 14.8 m in length and with a variety of wall thicknesses and facings. 4. The Alcove-Box is offered as an FRP or aluminum composite box and is available either fully assembled or as a self-build kit. 5. The integrated Plywood Timber and/or Steel ,Aluminum Embeded in the floor panel with connecting points for the suspension and optimal stiffnes.. An optional double floor for installing water tanks, batteries, and different floor heating solutions is available. This will optimize weight distribution and improve frost resistance. 6. A full range of doors, windows, hatches and skylights is available at prices tailored to your requirements.

Your Benefits

Freedom of Families

We have redefined Family travelling by introducing ‘Camper Box Independent’ models, incorporating the unrivalled features and benefits of the Self-Support Insulation Box concept. The GET VEHICLES are designed to fit all types of trucks. Their unique features make them truly different from any other expedition vehicles on the market From Flatbed Trucks to the Slide -in Camper with or without a Alcove.

True 4 season RV Box

Original German thermal technology insulation guarantee the True 4 season temperature inside the Camper.

Superior Safety and Healthy

Thanks to our best Insulation Core of XPS with fire-retardant grade "B" , According to EN 13501-01 to keep your box safe even in the fire alarm.

High Endurance

ANTI-PRESSURE:>180MPa

ANTI-CURVE: >220MPa

CUT STRENGTH: 24.6MPa

Delivered empty for you to outfit

Fullly DIY custimized for the box, can let you Make it into your luxury get away, your hunting hut, your mobile work shop,anything you want to be with families or loves.

Details & Ordering Guide

3659x2058x2185 Slide-In Camper Truck Box Perfect for FORD Dodge Chevrolet GMC PickUp

DESCRIPTION

EXTERIOR SIZE (MM)

INTERIOR SIZE(MM)

Panels

FRP SCS-HP Panel

2,440

2,058

2,185

2,340

1,958

2,085

RV & TC Box Type

Alcove Camper Box

Volume

10 m³

8.0 ft

6.8 ft

7.2 ft

7.7 ft

6.4 ft

6.8 ft

Panel Area

30 ㎡

Camper Design

Slide-In/Slide On Camper Box

ACH

1230

560

450

1219

865

0.0 in

48.4 in

22.0 in

17.7 in

48.0 in

34.1 in

* MCS Panel=Modular Composite Sandwich Panel /SCS Panel=Structural Composite Sandwich Panel;
-V =Vacuum Table Composite,-HP-Hydraulic Press Machine Composite

	Wall types	Thickness	Constructure
TC-RV Box Panel Details	Side Wall Panel	50.00mm	FRP + XPS +FRP
		Front Wall Panel	50.00mm	FRP + XPS +FRP
		Rear Wall Panel	50.00mm	FRP + XPS +FRP
		Roof Wall Panel	50.00mm	FRP + XPS +FRP Embeded 5 lines of PVC Tube for wire
		Floor Panel	50.00mm	FRP+Plywood 4mm + XPS +FRP. With Cross Beam Embeded
		Alcone Flat Panel	50.00mm	FRP + XPS +FRP

Door -Windows -other Hardwares

BOX INSTALLATION PROCESS

Aluminum Extrusion Installation

The "L" Alu.Extrusion rivert inside of the panels for the box installation. The used Aluminum profile andonized silver , heat treated , harden metal which is made Alloys,to wear resistance and strength to the box.

FRP-PIE MODULAR PANEL FINISHED BOX SHOW CASE

Windows Side Elevation

Tail Elevation

Door Side Elevation

Windows Side Elevation

Tail Elevation

Door Side Elevation

FAQ

Q '-What’s the material of your Truck Camper body?
A.- We can produce FRP (Fiberglass Reinforced Plastic), PPGI steel and Aluminum composite with XPS/PU insulation Sandwich panels for the truck camper box. The Core Material can be PU, XPS.

Q '- If want the price, what should offer us the information?
A.-You need offer us the material, size (LxWxH and the thickness of the panel) and quantity of the truck body as the basic
information. The sketch or the design drawing is much appreciated.

Q '-Can you pre-cut openings for windows and doors?
A.-We can offer this service with cost as we have embedded strengthen parts inside, but that will be confirmed before producing. your own Openings can easily be cut with a jigsaw and plastic rated blade, but the embedded strengthen parts cannot make. So if it will work in really bad expedition, you'd better let us pre-cut openings for windows and doors.

Q '-Can you do departure angles?
A.-Yes, we have two sizes of the box shape, one is the standard square shape, the other is the departure angle design. Please mark the desired angle (including dimensions) in the quoting template if you need.

Q '-Can you design subframes?
A.-We have the service of this, but you need supply the full chassis layout to us in advance.

Q '-Can I use different windows and doors than what’s listed on your specification?
A.-Yes. However, we highly recommend our windows and doors as they work in perfect balance with our camper bodies.

Q '-Can I order a camper body with an alcove?
A.-Yes. Please ask us for our alcove quoting template.

Q '–What’s included in the shipment?
A.-1. CKD type with All panels cut to size (other than departure angle), 2. CBU type with assembled box per your requirements.

Q '–Can you help with the interior layout?
A'–No. We are solely a camper body supplier, not a full-scale outfitter/design office.
